Rated Capacity |
8,000 lb (3,629 kg) |
Maximum Lift Height |
42' (12.8 m) |
Maximum Reach |
25' (7.6 m) |
Capacity @ Maximum Reach |
2,000 lb (905 kg) |
|
Machine Specifications |
Operating Weight |
22,500 lb (10,204 kg) |
Stowed Length |
24' (7.32 m) |
Stowed Width |
8'6" (2.59 m) |
Wheelbase |
10'10" (3.3 m) |
Outside Turning Radius |
14'9" (4.5 m) |
Ground Clearance |
17" (439 mm) |
Drive |
4 x 4 |
Steering |
All-Wheel |
Tires |
13:00 x 24 - 12 ply |
Maximum Travel Speed |
17.2 mph (27.7 kmph) |
Frame Tilt Left/Right Frame Leveling |
±10 Degrees |
|
|
|
