Snorkel MHP13/35 - Towable Boom
Platform |
Height |
35' (10.6m) |
Size |
46" x 28" (117 x 70 cm) |
Capacity |
500 lbs (227 kg) |
Construction |
Steel |
|
Machine Dimensions |
Overall Stowed Height |
6'5" (1.96m) |
Stowed Length |
20'4" (6 m) |
Width - Outriggers Stowed |
5'2" (1.58 m) |
Width - Outriggers Out |
12'1" (3.7 m) |
Stabilizer Footprint |
12'1" x 11'9" (3.7 x 3.6 m) |
Weight |
2601 lbs (1180 kg) |
Tire Size/Type |
165 x 13LT (pneumatic) |
|
Performance |
Horizontal Reach |
19'8" (6m) |
Power Source |
5.5hp Gasoline |
Turntable Rotation |
540° non-continuous |
Max Wind Speed |
28mph (45kph) |
|
|
|
|
